5 Best Oscilloscope Under 500 (Top 5 Picks in 2023)

Lots of oscilloscopes cost less than $500, but it’s hard to find a budget option that works well. We’ve researched and tested several cheap digital oscilloscope options available on the market and shortlisted some decent models.

You can choose the best oscilloscope under $500 with added features, like high quality, ease to use, and an affordable price range. Digital models are easier to use and have wider displays.

Choosing the right oscilloscope is essential to measuring electrical phenomena and quickly testing. From easy graphical displays to electrical signals, analyzing the waveform, and debugging circuit designs, the best oscilloscope under 500 can help you meet your goals.

In this guide, After our genuine and honest testing, I shortlisted and reviewed the top best oscilloscope under 500, along with my top 3 picks, so you can buy your winning product.

In 2001, when I was 15 years old, I started to use oscilloscopes to convey test results, and it’s been a carrier of mine ever since. I still exactly remember the first time I capture graphically displayed electrical signals and waveforms of signals to debug customer circuit designs.

Over the years, I’ve used a ton of digital oscilloscopes. I realize that When choosing the best oscilloscope under 500, you must consider a few crucial factors. That I will discuss in the last buying guide section. In this post, we’ll walk you through the best oscilloscope under 500 available in the marketplace based on price, performance, ease of use, and affordability.

Let’s first talk about these tools and get started exploring how to use them to fix issues…

What is the best oscilloscope under 500?

The best oscilloscope under $500 out there on the market is the Rigol DS1054Z and Siglent SDS1202X-E. They are the best ones because they are well within your budget, are easy to use, and offer a decent set of functionalities. But it’s also pretty darn useful for testing, verifying, and debugging the circuit board.

Here are my top picks for the best oscilloscope under 500 this year to help you for displaying complex signal waveforms to test and verify electronic circuits.

1. Siglent best oscilloscope (SDS1202X-E)

The second digital oscilloscope I have for you is Siglent SDS1204X-E. This new-generation oscilloscope is the best oscilloscope for beginners. It has a decent price tag in an affordable range.

I found that they have they provide strong technical support. They have a huge worldwide people of much satisfied with their easy-to-use signal display options. I love its Impressive sampling rate of 1 GSa/s for a single channel.

I am sure, That its amazing features will allow you to make it worth the extra money. I am sure that you will not get powerful 256-level intensity grading display oscilloscopes in this class.

To be fair, The best oscilloscope for beginners out there on the market is the Siglent SDS1204X-E. It is the best because it provides excellent signal fidelity, is easy to use, high-resolution screen, and has a decent price tag in this class.

Siglent SDS1204X-E is a high-quality oscilloscope with Great accuracy. I found that it is featured with a new generation of SPO technology makes troubleshooting easier.

What I Like/Dislike About Siglent:

Like:

  • Compact scope as compared to others.
  • Employ innovative digital trigger systems.
  • Perfectly suitable for a range of applications.
  • 7” LCD screen (800×480 resolution)
  • Low Power Consumption (Only 25W is very low in this class)

Dislike:

  • Only 2 channels But these are sufficient for normal analysis.

2. Rigol best oscilloscope under 500 (DS1054Z)

My #1 recommendation for an excellent oscilloscope is Rigol DS1054Z. I do not think Rigol needs any introduction If you want a simply amazing tool go for it. It has almost all the features required in a professional quality microscope. I love the model DS1054Z from Rigol.

I advise you to try it because It is a high-quality electronics testing instrument. Talking the Rigol, It has 4 channels and 50 MHz bandwidth.

The best oscilloscope for the money out there on the market is the Rigol DS1054Z. The oscilloscope also features USB and LAN ports, enabling connectivity and remote control from a computer.

It is the best because it provides the highest waveform capture rate, are easy to use, and has a decent affordable price in this segment. DS1054Z offers a clear and vibrant screen for waveform visualization and measurement readings

What I Like/Dislike About Rigol:

Like:

  • Great option as an upgrade.
  • Operates over 4 channels
  • 3-year warranty period.
  • Best-graded intensity displays on the market.

Dislike:

  • Fan noise can be disruptive.
  • Not a suitable choice for first-time owners.

3. best engineering oscilloscope from Hantek (DSO5102P)

The best engineering oscilloscope out there on the market is the Hantek DSO5102P. It is the best option engineers use to measure electrical phenomena to identify, test, verify, and fix circuit issues in quick ways.

It is featured with best-in-class dedicated onboard storage for storing several waveforms for analysis.

The Hantek DSO5102P is compact and lightweight definitely the right choice for hobbyists, beginners, and home users. The DSO5102P offers a bandwidth of 100 MHz, which allows for the measurement of a wide range of signals.

It has two analog channels and a maximum sample rate of 1 GSa/s. It offers multiple triggering modes, including edge, pulse, and video triggering,

The DSO5102P can be connected to a computer via a USB interface, allowing for remote control and data transfer.

What I Like/Dislike About Siglent:

Like:

  • Easy and portable Digital oscilloscope.
  • 3-year long warranty period.
  • Perfectly suitable for a range of applications.
  • Capable of storing up to 1000 waveforms.

Dislike:

  • Comparatively compact display in this class.

4. SainSmart DSO203 best oscilloscope under $500

The SainSmart DSO203 is a handheld digital Oscilloscope that offers a user-friendly interface. I love this device because it is easy to use and an advanced device in an affordable package.

The best part of this Oscilloscope is that it is durable and lightweight. It is a sturdy and compact device made of a plastic casing. I like the SainSmart DSO203 device because of built of rechargeable lithium-ion battery.


I checked that in a single charge you can use it non stop up to 8 hours. I also like the 3.2-inch TFT LCD display with a great resolution that helps in making easy-to-read waveforms. SainSmart DSO203 offers 4 channels and a built-in function generator is ideal for any testing.

Overall, It is an excellent choice for seeking in the affordable price range. Its compact size, good battery life, and affordable package make it a great choice for hobbyists.

What I Like/Dislike About SainSmart DSO203:

Like:

  • Easy and portable Digital oscilloscope.
  • Featured with a user-friendly interface.
  • Perfectly suitable for a range of applications.
  • DSO203 is relatively affordable in Price.

Dislike:

  • Comparatively compact display in this class.
  • Limited features compared to other advanced models.

Best Oscilloscope Under 500Buying Guide 2023

An Oscilloscope is used for analyzing electronic signals. This equipment basically displays the electronic signals in the form of a wave on screen with the help of which it is easier for a technician to determine the voltage function and its effect.

On the other hand, The device is very important as it shows the instant change in voltage in real-time, so choosing or buying it is a big challenge. In case if you choose the wrong one for yourself then it can create a blunder for you while working on electronic equipment.

So the question is how you can choose the best oscilloscope under 500 for use. And its simple answer is you can easily buy the best oscilloscope for your use by keeping some basic factors in your mind which are given below.

Factors that determine the best Oscilloscope in 2023

Here are some of the basic factors on the basis of which you can easily choose the best oscilloscope for yourself.

Digital or Analog

You can find various types of oscilloscopes that are best for your use and also fits your budget. Mostly the oscilloscopes that are lying under the range of 500 are likely to be digital ones.

The digital oscilloscope is quite accurate and better than the analog one and has additional features in it that can provide you with great convenience and reliability. The digital oscilloscope is more portable than the analog scopes. Analog scopes are generally heavier than those digital scopes.

Sample Rate

The number of samples of the reading taken by the oscilloscope per second is known as the sample rate. Must keep in mind that as the sample rate goes

Higher you will get a great resolution of the waveform of electronic signals which will help you to get more accurate faster signals. Generally, the sample rate displays the wave formed in Digital Scopes.

Bandwidth

Checking the range of the frequencies of the oscilloscope is considered to be one of the most important features that help you to get accurate measurements and readings. Getting those readings all depends on the bandwidth of an oscilloscope.

If you want to get a more accurate representation of the waveform of the electronic signals then the bandwidth of your Oscilloscope should be five times higher than the frequency of the signal. Higher the frequency more costly the bandwidth.

Matching Probes

Oscilloscope consists of two parts that are a scope and a probe. Many people consider the scope as the important part and literally ignore the probe which is a very wrong way to buy an oscilloscope.

There are various types of probes that are available. The probes fit only with certain scopes, some of which are mentioned below.

  • Passive probes: Most suitable for ground-referenced measurements.
  • Logic probes: Used for delivery of digital signals.
  • High voltage differential probes: Good for taking safe accurate differential and floating measurements.
  • Current probes: Good for measuring current as well as power change.

Ease of Use

Must buy those oscilloscopes which are convenient for your use. Must check its built-in help menu as well as its display, ability to zoom waveform, and how to control it easily.

Number of Inputs

One of the most important factors that help to choose the best oscilloscope is the number of channels in it. Basically, it allows you to understand how many signals you can view and analyze at a time.

Price

Many people often invest a great amount and buy very high specs equipment that is not for their use. Money is one of the most important factors in terms of buying anything so before you buy or choose an oscilloscope check your needs and requirements and then invest money in it.

Rise time

The time taken by a signal to move 10 to 90% in a form of a rising wave is termed rice time which is also a factor that cannot be ignored while buying an oscilloscope.

Length of records

The sample rate or the record length feature of an oscilloscope is the last but not the least factor that cannot be ignored. The record length is the thing that helps you to analyze the number of points in a way form considered by an oscilloscope that is used in creating a record of a signal.

You may also like: How to Use An Oscilloscope

In the below Video, tutorial Learn tips & tricks and hear from industry experts. Everything you need to know How to Use an Oscilloscope.

Conclusion

I hope you enjoy the article. This will help you choose the best oscilloscope under 500 available in the marketplace. If you have further any doubt you can check my buying guide. Definitely, this will help to get your winning product.

To tackle circuit board testing-related issues, we need to have the best oscilloscope under 500 in our homes. As a reminder, You have to select your best oscilloscope’s preferred budget range very carefully. For that, you need to focus on determining factors as given in buying guide section.

So that is all about it. That is all I want to share about some best oscilloscopes under 500. I hope kind of helpful to you and enjoyed it.
